Genelec 8350A 8″ Powered Bi-amplified Studio Monitor

Genelec 8350A 8″ Powered Bi-Amplified Studio Monitor

Styled in a white finish, the Genelec 8350A is a single SAM-Series, 2-way active studio monitor designed to provide accurate mix referencing with extended low frequencies and software control capabilities for audio engineers, musicians, and producers in project studios, medium- to large-sized control rooms, commercial facilities, or mastering rooms. It features 350W of Class-D amplification driving an 8″ woofer and a 1″ tweeter, producing a frequency response of 33 Hz to 22 kHz.

A proprietary waveguide enhances imaging, while the bass reflex port extends the low-frequency response. The die-cast aluminum enclosure is shaped to minimize diffraction and reflections. XLR connectors are provided for the balanced analog input and AES/EBU digital input and output. Built-in signal overload protection enhances dependability and protects the speaker. Rear-panel room compensation controls include levels and high- and low-frequency adjustments. Detailed frequency adjustments and automatic calibration can be performed via GLM (Genelec Loudspeaker Manager) software and the GLM User Kit (available separately). A selectable power-saving mode enables automatic power up/down via a signal-sensing circuit.

The 8350A offers multiple mounting options including an Iso-Pod isolation stand and threaded holes that are compatible with select K&M mounts and various wall/ceiling brackets.

• 6.5″ woofer and 3/4″ tweeter
• 150W LF amp and 150W HF amp
• 38 Hz to 23 kHz frequency response (-6 dB), 45 Hz to 20 kHz frequency response (±1.5 dB)
• Proprietary waveguide utilizes DCW (Directivity Control Waveguide) technology for improved imaging and a wider listening area
• Bass reflex port provides extended low-frequency response
• Rear-panel room compensation controls including high- and low-frequency adjustments
• Supports automatic calibration via software control
• Low-diffraction aluminum enclosure utilizes MDE (Minimum Diffraction Enclosure) technology
• XLR connections for balanced analog input and digital AES/EBU input and output
• ISS (Intelligent Signal Sensing) automatic power-saving mode
• Multiple mounting options: Iso-Pod and threaded holes that are compatible with select K&M mounts and various wall/ceiling brackets
• Includes Iso-Pod isolation stand for vibration decoupling

Key Features:

• 8″ Woofer, 1″ Metal-Dome Tweeter
• 350W Class-D Amplification
• Proprietary Waveguide, Bass Reflex Port
• High- and Low-Frequency Controls
• Supports Software Control & Calibration
• Low-Diffraction Aluminum Enclosure
• XLR Analog and Digital Inputs
• Selectable Automatic Power-Saving Mode
• Multiple Mounting Options
• Includes Isolation Stand

To learn more about Genelec, Click Here

View more products from Genelec

• Monitor Type & Configuration: Active 2-Way
• Total Power Output: 350 W
• Tweeter: 1x 1" / 25 mm Metal Dome
• Woofer: 1x 8" / 20.5 cm Cone
• Frequency Range: 33 Hz to 22 kHz (-6 dB)
• Audio I/O: 1x XLR 3-Pin Balanced Input (10 Kilohms)
• Digital Audio I/O:
• 1x XLR 3-Pin AES3 Input
• 1x XLR 3-Pin AES3 Out/Thru
• Network I/O: 2x RJ45 Ethernet
• Number of Included Monitors: Single Monitor
• Enclosure: Bass-Reflex/Ported, Shielded
• Total Power Output: 350 W

Drivers:

• Tweeter: 1x 1" / 25 mm Metal Dome
• Woofer: 1x 8" / 20.5 cm Cone
• Amplifiers:
• HF: 1 x 150 W Class-D
• LF: 1 x 200 W Class-D

Performance:

• Frequency Range: 33 Hz to 22 kHz (-6 dB)
• Frequency Response: 38 Hz to 20 kHz ± 1.5 dB
• Maximum Sound Pressure Level (SPL): 121 dB
• Signal-to-Noise Ratio: 109 dBA
• Total Harmonic Distortion (THD): 0.01%
• Maximum Input Level: +25 dBu
• Analog Input Sensitivity/Gain: +6 to -6 dBu (Continuously Variable)
• Self-Generated Noise: Less Than 5 dBA (at 3.28' / 1 m)

Signal Processing:

• EQ:
• 2x LF Shelf
• 2x HF Shelf
• Filters: 16 x Parametric Notch Filter
• Crossover Frequency: 1.8 kHz
• Maximum Sampling Rate: 192 kHz / 24-Bit

Connectivity:

• Audio I/O: 1x XLR 3-Pin Balanced Input (10 Kilohms)
• Digital Audio I/O:
• 1x XLR 3-Pin AES3 Input
• 1x XLR 3-Pin AES3 Out/Thru
• Network I/O: 2x RJ45 Ethernet
• USB: No
• Wireless: No

Power:

• AC Input Power: 100 to 240 VAC, 50/60 Hz
• Power Consumption:
• 1 W (Standby)
• 12 W (Idle)
• 230 W (Maximum)
• Enclosure Material: Aluminum
• Dimensions (W x H x D): 11.3 x 17.8 x 10.9" / 28.6 x 45.2 x 27.8 cm
• Weight: 28.2 lb / 12.8 kg
