500 Series Signal Processors
500 Series modular processor, preamp, compressor, EQ, and more!
Customize your rack with all the right tools for the job.
Sonic Circus offers 500 Series from API, Rupert Neve, SSL, Chandler, and many more.
Balanced Attenuator Pack W/ 8 rotary balanced faders, db25 standard analog I/O, Stereo or mono selectable, Passive 5k ohm impedance, Post mic pre attenuation, Stepped volume controls.
Sample Rate: 192kHz to 12kHz, Resolution: 24 bits, Minimum Delay: 0.11 milliseconds, Maxiumum Delay: 10 seconds @ 192kHz 60 seconds @ 12kHz, Input: Max 24dBu, 18k impedance, Output: Max 24dBu, 50 impedance, Insert Send: Max 10dBu, 2k impedance, Insert Return: Max 20dBu, 50k impedance, Power: +16V 200mA, -16V 100mA
2 Slot Horizontal 19" Rack for 80 Series Modules, Independent Phantom 48V switches and Output Faders, Built-in Compression Link Buss, Internal 24V PSU. XLR I/O, 3RU Chassi
8 Slot Vertical Rack for 80 Series Modules, 8 Independent Phantom 48V switches and Output Faders, 2 Built-in Compression Link Busses, External 24V PSU. XLR I/O, 19" 5RU Chassi
8-Slot 500 Series Chassis with Integrated 10-channel Summing Mixer, Individual Pan, Fader, and 48V Phantom. Master Fader, External +_16V PSU. 3RU 19" Rackmount. DB25 and XLR I/O Daisychainable
Features Continuously variable detented Gain, Threshold, Attack, Ratio and Release controls, 10 segment LED meters, Over Threshold LED, Patented THRUST Switch, 3 selectable compressor curve Knee settings, Selectable New or Old switch, Selectable variable or auto compressor, Audio circuit uses 2520 and 2510 Discrete Op Amps with transformer output.
The karacter 500 is a box full of vibrant colors. It covers a complete spectrum including mastering-grade saturation, tube-inspired distortion and glorious destruction.
Rack Ears are available for both the current production model lunchboxes (product number: 920-0859), as well as the previous model (product number: 920-0737), Made from aluminum and finished with a durable black coat.
Features, Mic Preamp with 65 dB of gain, Variable Output Level Control, 3:1 Output Transformer Tap Selection, Front and Back Panel Mic Input Access, Line/Instrument Preamp with 45 dB of gain.
Features, Polarity button, 20dB Input Pad, Calibrated Level mode, Output Ratio selector, Clip LED indicator, Continuously variable Output Gain, Traditional API fully discrete circuit design.
