RCF Installed Sound SUB-S15 Passive 15″ Bass Reflex Subwoofer

RCF Installed Sound SUB-S15 Passive 15″ Bass Reflex Subwoofer

S 15 is a high-power, compact subwoofer system ideal for installations where the physically small size and impact of a 15” driver are desired. Extending the frequency response below 35Hz, this highly efficient design is capable of providing output levels normally associated with considerably larger enclosures. A system suited to music playback in applications ranging from clubs, bars and cafes, right through to theatres and corporate applications. The low-frequency transducer is a 15″ woofer with a 2.5″ voice coil. Its design is the result of the latest refinements in compact subwoofer production, resulting in a fast and controlled reproduction of the bass frequency range. It is particularly well-suited for high-quality multimedia applications.

Powerful lows

RCF subwoofers are the first choice of many sound engineers, due to their very high SPL levels at very low frequencies, smaller dimensions compared to the competitors, and impressive size/weight to SPL output ratio. Your audience will enjoy an engaging immersive musical experience.

State of the art transducers

The low-frequency transducers are a 10”, 12″ and a 15” high-power woofers, both with a 2.5” voice coil. Their design is the result of the latest refinements in compact subwoofers production, resulting in a fast and controlled reproduction of the bass frequency range.

Multipurpose sound

Elegant design aesthetic, multiple formats and RCF signature sound quality that allows to deliver a supreme audio experience in any application, from restaurant and retail shops to clubs, corporate spaces and venues.

Improve the audio atmosphere

Music helps engagement and will improve the hospitality of your activity, especially if the perceived sound quality is higher. This is the aim of RCF SUB S Series – optimal performance in both background music and high-powered foreground audio.

Features

• 500W AES power handling
• 126 dB max SPL
• 35 ÷ 200 Hz frequency range
• 1 x 15″ high-power woofer
• High-quality plywood cabinet
• Steel front grille with clothing
• M20 standard pole mount in the top section of the cabinet
• 4 pole EUROBLOCK connector (audio input and parallel link output)

Acoustical Specifications:

• Frequency Response (-10dB): 35 Hz ÷ 200 Hz
• Max SPL @ 1m: 126 dB
• System Sensitivity: 95 dB

Power Section:

• Amplification: Full Range
• Nominal Impedance: 8 ohm
• Power Handling: 500 W RMS
• Peak Power Handling: 2000 W PEAK
• Recommended Amplifiers: QPS 6.0K, IPS 2.5K, IPS 1.5K, DMA 504

Transducers:

• Woofer: 1 x 15'', 3.0'' v.c

Input/Output Section:

• Input Connectors: Euroblock
• Output Connectors: Euroblock

Standard Compliance:

• Safety Agency: CE compliant

Physical Specifications:

• Cabinet/Case Material: Plywood
• Hardware: 12 x M10
• Pole Mount/Cap: Yes
• Grille: Steel with clothing
• Color: Black

Size:

• Height: 443 mm / 17.44 inches
• Width: 630 mm / 24.8 inches
• Depth: 500 mm / 19.69 inches
• Weight: 27.5 kg / 60.63 lbs
