RCF IPS-1700 2 X 450 W Class H Professional Power Amplifier
$699.00
Please check with us about availability
Description
IPS Series is a range of two-way professional amplifiers that combines high quality performance and reliability with the latest power amplifications technologies. This high value power-to-cost designs offer, in compact lightweight 2 rack unit space, the sound quality and the durability of traditional class AB and class H designs with the innovation of the latest power devices available. IPS 1700 is a 2 channel power amplifier that delivers up to 2 x 450 W RMS @ 4 O (900 W RMS bridged @ 8 O), weighing just 12,7 kg. It features independent gain dials, signal – clip and fault LEDs, stereo XLR input and Output link, 1.4 V to 0.775 V input sensitivity switch, mono – stereo – bridge switch, powercon outputs. Moreover, it is protected against shorts and open circuits. Thanks to its high efficiency heat sinks and high speed DC fans, the IPS 1700 can withstand the hardest heat conditions ensuring great reliability.
Features:
- 2 Unit 19″ Rack, Easy Transportation
- Fast Response And Low Distortions
- Easy To Configure In Stereo / Mono / Bridge Modes
- Extensive Protective Circuits Ensure High Reliability And Operating Safety.
- Front Panel Signal / Clip / Protect Led Indicators
- Xlr Input Connectors
- Speakon Nl4 Output Connectors
Additional information
| Brand | RCF |
|---|---|
| Condition | New |
Technical Specifications
- Crosstalk (@ 1 KHZ): <75 dB
- Distortion (THD+N) @ 1 KHZ Nominal Power: <0.5 %
- Frequency Response (-3DB): 20 Hz ÷ 20 kHz
- Number Of Channels: 2
- Power Output (Bridged @ 8 OHM): 900 W RMS
- Power Output Per Channel (@ 4 OHM): 450 W RMS
- Power Output Per Channel (@ 8 OHM): 330 W RMS
- Signal/Noise Rate (”A” Weighted): >100 dB
- Configuration: DIP switch, Front panel
- Balanced: 2
- Line Connectors: XLR
- Line Inputs: 2
- MONO: 2
- Total Number Of Inputs: 2
- Signal Output Connectors: XLR
- Power Output Connectors: Speakon
- Signal Output Number: 2
- Cabinet/Case Material: Metal
- Color: Black
- Rack Mounting: 19", 2U
- Operating Voltage: 220-240/115 V~ 50/60Hz
- Power Consumption: 350 W
- Cooling: Forced
- DC Delay: Yes
- Fuses: Yes
- Short Circuit: Yes
- Thermal: Yes
- VHF: Yes
- Depth: 255 mm / 10.04 inches
- Height: 88 mm / 3.46 inches
- Weight: 11.1 kg / 24.47 lbs
- Width: 482 mm / 18.98 inches
- CE Marking: Yes
- EN54-16 Certified: Yes
Download Specification Sheet for RCF IPS-1700 2 X 450 W Class H Professional Power Amplifier
