Undertone Audio DI & Re-amper GB Tracker

Completely Invisible-Sounding

This unique design features detent’ed gain-matching input and output level controls that allow you to always maintain a precise unity gain through the DI to the re-amplification path. This, combined with our painstaking effort to match the commonly used impedances on popular guitars, basses, and amps, makes the GB Tracker sonically transparent. Your guitar or bass going through the GB Tracker will sound exactly the same as plugging directly into your amp.

Revolutionized Workflow

This system was designed to enable an effortless and seamless workflow while preserving the sonic integrity of the instruments and amps being used. Once the GB Tracker is in the recording setup, the benefits of editing, processing and re-amping the captured performances are only a flip of a switch away. The power to perfect performances and tones has never been so easy.

To learn more about Undertone Audio, Click Here

View more products from Undertone Audio.

Input Voltage: 24V AC (200mA)
Input Impedance

• Instrument Input: 1Mohm, 4.7Mohm, 5.7Mohm
  (internally selectable)
• From DAW: 15Kohm

Output Impedance

• To AMP: 2Kohm
• To DAW: 47ohm

Frequency Response

• “INPUT” to “DAW OUTPUT“: 20Hz - 50KHz 0dB to -1dB
• “FROM DAW” to “TO AMP”: 20Hz - 40KHz 0dB to -1dB

Max Level Before Clip with 600Ω Load

• To DAW: +24dBm

Distortion

• “INPUT” to “DAW OUTPUT“: <0.02% THD 20Hz-20kHz @+20dBu

Dimensions

• GB Tracker: 1.93”(H) X 6.18”(D) X 7.2”(W)

Weight

• GB Tracker: 2.4 Lbs
